AA3528SESK/J4

$0.71

Description：LED ORANGE CLEAR SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:b4a6abafd5f1 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AA3528SESK/J4 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED ORANGE CLEAR SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for AA3528SESK/J4

Description：LED ORANGE CLEAR SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Orange
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：800mcd
Lens Style：Round with Flat Top
Lens Size：2.40mm Dia
Voltage - Forward (Vf) (Typ)：2.2V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount
Wavelength - Dominant：605nm
Wavelength - Peak：611nm
Features：-
Package / Case：2-PLCC
Supplier Device Package：SMD
Size / Dimension：3.20mm L x 2.80mm W
Height (Max)：2.10mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for AA3528SESK/J4

AA3528SESK/J4

LED Indication - Discrete Overview

The AA3528SESK/J4 is a single-color surface-mount LED manufactured by Kingbright, designed for high-intensity visual signaling. It emits orange light with a peak wavelength of 605 nm and features a water-clear lens to maximize luminous output. The component delivers a nominal light intensity of 2800 mcd at a forward current of 20 mA, with a forward voltage of 2.2 V. It operates within a temperature range of -40°C to +85°C and utilizes a standard 1411 (3528 metric) package footprint.

LED Indication - Discrete Feature Summary

High luminous intensity output suitable for clear visibility applications
Water-clear lens design enhances light transmission efficiency
Standard SMD package dimensions facilitate automated assembly processes

LED Indication - Discrete Applications

Machine status indicators
Control panel signal lights
Industrial equipment monitoring displays

LED Indication - Discrete Procurement Notes

Verify the specific suffix configuration against official Kingbright documentation to ensure correct optical and electrical characteristics. Confirm moisture sensitivity level handling requirements during storage and soldering. Cross-reference the datasheet for precise binning specifications regarding wavelength and intensity to match application tolerances.

LED Indication - Discrete Selection Notes

Select this component when high-brightness orange indication is required in space-constrained designs. The 1411 package offers a balance between thermal performance and board space efficiency. Ensure the driving circuit supports the specified 20 mA forward current and 2.2 V forward voltage drop for optimal operation and longevity.

LED Indication - Discrete Part Context

This part belongs to Kingbright's AA series of surface-mount LEDs, which are widely used in electronic devices requiring reliable visual feedback. The 3528 metric package is a standard industry form factor, allowing compatibility with existing PCB footprints designed for similar-sized components across various manufacturers.
