AA4040SECK

Description：LED ORANGE CLEAR SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:4363049a4132 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

AA4040SECK is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED ORANGE CLEAR SMD R/A. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for AA4040SECK

Description：LED ORANGE CLEAR SMD R/A
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Orange
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：300mcd
Lens Style：Round with Flat Top
Lens Size：2.40mm Dia
Voltage - Forward (Vf) (Typ)：2.1V
Current - Test：20mA
Viewing Angle：90°
Mounting Type：Surface Mount, Right Angle
Wavelength - Dominant：601nm
Wavelength - Peak：610nm
Features：-
Package / Case：2-SMD, Boomerang
Supplier Device Package：SMD
Size / Dimension：4.00mm L x 3.60mm W
Height (Max)：4.00mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for AA4040SECK

AA4040SECK

LED Indication - Discrete Overview

The AA4040SECK is a single-color surface-mount LED from the Kingbright AA4040 series. It features an orange lens with a water-clear finish and a round shape measuring 2.4 mm in diameter. The component has a 4.0 x 4.0 mm footprint, a maximum height of 4.0 mm, and utilizes a PLCC-2 package for right-angle mounting. It operates at a peak wavelength of 610 nm with a forward voltage of 2.1 V at 20 mA test current.

LED Indication - Discrete Feature Summary

Right-angle surface mount configuration for compact PCB layouts
Water-clear lens material to maximize light transmission
High temperature resistant construction for thermal stability

LED Indication - Discrete Applications

Industrial control panel indicators
Electronic equipment status signaling
Consumer appliance front panels

LED Indication - Discrete Procurement Notes

Verify the specific suffix against manufacturer documentation to confirm exact optical characteristics and packaging type. Ensure compatibility with standard SMD reflow profiles and check moisture sensitivity levels prior to assembly.

LED Indication - Discrete Selection Notes

Select this component when a right-angle orientation is required within a 4x4 mm envelope. Consider the 610 nm peak wavelength for visibility requirements and verify that the 2.1 V forward voltage aligns with the driving circuit design.

LED Indication - Discrete Part Context

This part belongs to the AA4040 family of high-temperature single-color LEDs. The series offers various color options in a standardized PLCC-2 package, providing designers with consistent mechanical dimensions while allowing flexibility in optical output specifications.
