Product Detailed Parameters
- Description：LED YELLOW CLEAR SOT23-3 SMD
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR)
- Color：Yellow
- Configuration：Standard
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：130mcd
- Lens Style：Rectangle with Flat Top
- Lens Size：3.00mm x 1.30mm
- Voltage - Forward (Vf) (Typ)：2V
- Current - Test：20mA
- Viewing Angle：140°
- Mounting Type：Surface Mount
- Wavelength - Dominant：590nm
- Wavelength - Peak：590nm
- Features：-
- Package / Case：TO-236-3, SC-59, SOT-23-3
- Supplier Device Package：SOT-23-3
- Size / Dimension：3.00mm L x 1.30mm W
- Height (Max)：1.20mm
- Grade：-
- Qualification：-
Download product information
Overview
The AM23SYC-F is a surface mount LED lamp manufactured by Kingbright Corporation. It features a compact form factor designed for integration into electronic assemblies requiring indicator lighting. The component utilizes surface mount technology to facilitate automated placement and soldering processes on printed circuit boards. This specific model is part of the broader range of surface mount LED lamps produced by the manufacturer, intended for applications where space constraints and manufacturing efficiency are primary considerations.
Feature Summary
- Surface mount construction for automated PCB assembly
- Compact footprint suitable for space-constrained designs
- LED lamp configuration for visual indication
Applications
- Electronic device status indicators
- Control panel illumination
- Consumer electronics signaling
Procurement Notes
Verify the exact electrical characteristics and optical specifications against the official Kingbright datasheet before procurement. Ensure compatibility with existing design parameters. Confirm package dimensions and pin configuration match the target PCB layout. Check for any specific handling or storage requirements outlined in the manufacturer documentation.
Selection Notes
Select this component based on its surface mount capability and physical size relative to available board space. Evaluate the optical output requirements against the LED's performance characteristics. Consider the manufacturing process compatibility, specifically reflow soldering profiles, to ensure reliable attachment during assembly without damaging the component.
Part Context
This component belongs to Kingbright's portfolio of surface mount LEDs. These devices are engineered for high-volume manufacturing environments. The series offers various configurations to meet diverse industrial and consumer needs. The AM23SYC-F represents a standard option within this lineup, focusing on reliability and ease of integration into modern electronic systems.
Replacement Considerations
Consult the Kingbright datasheet for direct equivalents or cross-references. Verify that any substitute maintains identical pinout, thermal characteristics, and mechanical dimensions. Ensure optical performance metrics align with the original design intent before implementing a replacement part.
