B1360W

Antennas RF Overview

The TE Connectivity B1360W is a wideband VHF mobile load coil antenna designed for the 136-174 MHz frequency range. It features a 1/2 wave configuration with unity gain and requires no tuning. The unit has a vertical polarization and measures 495.3 mm in height. It includes a UV-treated radome to resist sun damage, ensuring durability in outdoor environments.

Antennas RF Feature Summary

• Wideband operation across 136-174 MHz without tuning requirements
• UV-treated radome for resistance to sun damage
• Vertical polarization suitable for mobile applications

Antennas RF Applications

• Land Mobile Radio (LMR)
• VHF mobile communications
• Wideband radio systems

Antennas RF Procurement Notes

Verify that the specific order matches the B1360W part number to ensure correct frequency coverage of 136-174 MHz. Confirm RoHS compliance status if required by project specifications. Check physical dimensions against mounting constraints due to the 495.3 mm height. Ensure compatibility with vehicle mounting interfaces for mobile land radio applications.

Antennas RF Selection Notes

Select this model when a wideband VHF solution covering 136-174 MHz is needed without manual tuning. The unity gain design suits standard mobile radio needs. Consider the 495.3 mm height for clearance. The UV-treated radome makes it suitable for permanent outdoor or vehicular exposure where sun damage resistance is critical for longevity.

Antennas RF Part Context

This component belongs to TE Connectivity's line of wideband mobile load coil antennas. It is engineered for VHF band operations, specifically targeting land mobile radio systems. The design integrates a 1/2 wave structure to provide consistent performance across the specified frequency range without the need for adjustment.

Antennas RF Replacement Considerations

No public confirmed substitute part numbers are available.
