CRA12TH

Overview

The nVent Hoffman CRA12TH consists of L-shaped rack-mount angles designed for 19-inch rack equipment installation within 24-inch wide enclosures. Constructed from 14-gauge steel with a clear zinc-plated finish, these components provide structural support for mounting hardware. The angles feature through-holes with a diameter of 0.281 inches (7 mm) to facilitate secure attachment to enclosure flanges or adjustable-depth mounting kits.

Feature Summary

• L-shaped design for stable rack mounting
• Clear zinc-plated steel construction
• Compatible with 19-inch rack equipment in 24-inch enclosures

Applications

• Mounting 19-inch rack equipment in 24-inch wide enclosures
• Attachment to enclosure flanges
• Installation using adjustable-depth mounting kits

Procurement Notes

Verify that the target enclosure width is exactly 24 inches to ensure proper fitment of the CRA12TH rack-mount angles. Confirm that the installed equipment adheres to standard 19-inch rack dimensions. Check that the mounting method utilizes either the enclosure flange or an adjustable-depth kit compatible with the 7 mm hole diameter specified for this component.

Selection Notes

Select the CRA12TH specifically when installing 19-inch rack-mounted devices into 24-inch wide Hoffman enclosures. This model provides the necessary depth and structural integrity for rack systems. Ensure the application requires L-shaped angles rather than other mounting profiles. Verify that the 14-gauge steel material and clear zinc plating meet the environmental protection requirements for the installation site.

Part Context

The CRA12TH is part of the Hoffman Concept series of enclosure accessories. It serves as a critical mounting solution for organizing electronic and industrial control equipment within standardized cabinet sizes. These angles are engineered to integrate seamlessly with other Hoffman mounting hardware, ensuring a robust and secure assembly for rack-based installations.

Replacement Considerations

No public confirmed substitute part numbers are available.
