E91F451VNT182MCA5U

E91F451VNT182MCA5U is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM 1800UF 20% 450V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for E91F451VNT182MCA5U

• Description：CAP ALUM 1800UF 20% 450V SNAP TH
• Series：U91F
• Mfr：Chemi-Con
• Package：Bulk
• Capacitance：1800 µF
• Tolerance：±20%
• Voltage - Rated：450 V
• ESR (Equivalent Series Resistance)：55mOhm @ 120Hz
• Lifetime @ Temp.：5000 Hrs @ 105°C
• Operating Temperature：-25°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：-
• Ripple Current @ Low Frequency：7.1 A @ 120 Hz
• Ripple Current @ High Frequency：10.153 A @ 100 kHz
• Lead Spacing：0.984" (25.00mm)
• Size / Dimension：1.969" Dia (50.00mm)
• Height - Seated (Max)：4.232" (107.50mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In - 5 Lead

Aluminum Electrolytic Capacitors datasheet and documents for E91F451VNT182MCA5U
