ECW-H16302JVB

ECW-H16302JVB is listed in the Film Capacitors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is CAP FILM 3000PF 5% 1.6KVDC RAD. Review the specifications below when checking this part for your BOM.

Film Capacitors specifications for ECW-H16302JVB

• Description：CAP FILM 3000PF 5% 1.6KVDC RAD
• Series：ECW-H(V)
• Mfr：Panasonic Electronic Components
• Package：Bulk
• Capacitance：3000 pF
• Tolerance：±5%
• Voltage Rating - AC：-
• Voltage Rating - DC：1600V (1.6kV)
• Dielectric Material：Polypropylene (PP), Metallized
• Operating Temperature：-40°C ~ 105°C
• Mounting Type：Through Hole
• Package / Case：Radial
• Size / Dimension：0.709" L x 0.295" W (18.00mm x 7.50mm)
• Height - Seated (Max)：0.748" (19.00mm)
• Termination：PC Pins
• Lead Spacing：0.394" (10.00mm)
• Applications：High Frequency, Switching
• Ratings：-
• Features：-

Film Capacitors datasheet and documents for ECW-H16302JVB
