EHF-125-01-S-D-SM-LC-K

Headers, Male Pins Overview

The EHF-125-01-S-D-SM-LC-K is a rectangular board connector manufactured by Samtec Inc. It features 70 contacts arranged in two rows with male pin terminals. The component utilizes a 1.27 mm (0.050 inch) pitch and is designed for surface mount installation. Contact finishes include gold plating on the mating interface and matte tin on the solder termination. The housing is black phosphor bronze, and the unit is compliant with RoHS standards.

Headers, Male Pins Feature Summary

• Integrated ejector header mechanism for secure connection
• Low contact force design to protect PCB pads
• Shrouded terminal configuration for alignment

Headers, Male Pins Applications

• High-density board-to-board interconnects
• Surface mount electronics assembly
• Industrial control system connections

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm the exact configuration of the low contact force option and surface mount variant. Ensure that the procurement specifications match the required pin count and row arrangement for the target application.

Headers, Male Pins Selection Notes

Select this component when a shrouded, surface-mount header with an integrated ejector mechanism is required. The low contact force feature is critical for applications where minimizing insertion stress on the printed circuit board is necessary. Confirm compatibility with mating socket connectors before finalizing the design.

Headers, Male Pins Part Context

This part belongs to the EHF series of ejector headers from Samtec. These components are engineered for high-reliability connections in compact electronic assemblies. The series offers various mounting styles and contact configurations to support diverse industrial and commercial hardware requirements.

Headers, Male Pins Replacement Considerations

Consult official Samtec substitution guides for compatible alternatives. Verify mechanical dimensions and electrical ratings before swapping with other series components.
