EKZN800ELL821MM25S

EKZN800ELL821MM25S is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM 820UF 20% 80V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EKZN800ELL821MM25S

• Description：CAP ALUM 820UF 20% 80V RADIAL TH
• Series：KZN
• Mfr：Chemi-Con
• Package：Bulk
• Capacitance：820 µF
• Tolerance：±20%
• Voltage - Rated：80 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：10000 Hrs @ 105°C
• Operating Temperature：-40°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.65 A @ 120 Hz
• Ripple Current @ High Frequency：2.75 A @ 100 kHz
• Lead Spacing：0.295" (7.50mm)
• Size / Dimension：0.709" Dia (18.00mm)
• Height - Seated (Max)：1.043" (26.50mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：27 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for EKZN800ELL821MM25S
