EMHS500ARA101MHA0G

EMHS500ARA101MHA0G is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM 50V POLAR. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EMHS500ARA101MHA0G

• Description：CAP ALUM 50V POLAR
• Series：Alchip™- MHS
• Mfr：Chemi-Con
• Package：Tape & Reel (TR),Cut Tape (CT)
• Capacitance：100 µF
• Tolerance：±20%
• Voltage - Rated：50 V
• ESR (Equivalent Series Resistance)：650mOhm @ 100kHz
• Lifetime @ Temp.：2000 Hrs @ 125°C
• Operating Temperature：-40°C ~ 125°C
• Polarization：Polar
• Ratings：AEC-Q200
• Applications：Automotive
• Ripple Current @ Low Frequency：176 mA @ 120 Hz
• Ripple Current @ High Frequency：440 mA @ 100 kHz
• Lead Spacing：-
• Size / Dimension：0.315" Dia (8.00mm)
• Height - Seated (Max)：0.413" (10.50mm)
• Surface Mount Land Size：0.327" L x 0.327" W (8.30mm x 8.30mm)
• Mounting Type：Surface Mount
• Package / Case：Radial, Can - SMD
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for EMHS500ARA101MHA0G
