FMWAN028-10

Antennas RF Overview

The FMWAN028-10 is a WR-28 waveguide horn antenna manufactured by Fairview Microwave, designed for operation within the 26.5 GHz to 40 GHz frequency range. It features a UG-599/U flange configuration and provides a gain of 10 dBi. This component serves as a dual-polarized probe antenna suitable for high-frequency signal transmission and reception applications in millimeter-wave systems.

Antennas RF Feature Summary

• Operates as a waveguide horn antenna within the WR-28 standard
• Provides 10 dBi gain across the specified frequency band
• Features dual polarization capabilities for versatile signal handling
• Utilizes a UG-599/U flange for secure mechanical connection

Antennas RF Applications

• Millimeter-wave communication systems
• Test and measurement instrumentation
• Radar system components
• Satellite ground station equipment

Antennas RF Procurement Notes

Verify the specific datasheet version and technical specifications directly with Fairview Microwave or authorized distributors before procurement. Ensure that the UG-599/U flange interface matches your existing waveguide infrastructure. Confirm operational frequency requirements align with the 26.5 GHz to 40 GHz range to guarantee optimal performance and compatibility within your system design.

Antennas RF Selection Notes

Select this model when a fixed-gain, dual-polarized solution is required for the E-band spectrum. The WR-28 form factor dictates physical integration constraints compared to coaxial alternatives. Consider the 10 dBi gain level against system link budget requirements. Verify that the UG-599/U flange type is compatible with your current waveguide assembly standards and mounting configurations.

Antennas RF Part Context

This component belongs to Fairview Microwave's line of RF connector accessories and waveguide antennas. It is categorized under wireless and RF integrated circuits, specifically serving as a passive radiating element. The product supports high-frequency applications requiring precise waveguide interfaces and standardized flange connections for reliable signal integrity.

Antennas RF Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Evaluate alternative WR-28 waveguide horns from other manufacturers only if they match the UG-599/U flange specification and 26.5–40 GHz frequency range exactly.
