GNSS1-TMG-26NMSCL

Antennas RF Overview

The GNSS1-TMG-26NMSCL is a dome-style RF antenna manufactured by Amphenol PCTEL, designed for global navigation satellite systems. It operates at a center frequency of 1.5845GHz with a bandwidth spanning 1.554GHz to 1.615GHz. The unit provides a gain of 3dBic and maintains a Voltage Standing Wave Ratio (VSWR) of 2. It features an N-type female connector and utilizes base mounting. Integrated Low Noise Amplifier (LNA) and filter components enhance signal integrity.

Antennas RF Feature Summary

• Integrated LNA and filter for improved signal processing
• Dome form factor suitable for base installation
• Supports multiple global navigation satellite constellations

Antennas RF Applications

• GPS positioning systems
• GLONASS receiver integration
• Galileo navigation applications
• BeiDou system implementation
• General GNSS timing infrastructure

Antennas RF Procurement Notes

Verify the specific suffix 'SCL' against the manufacturer's current datasheet to confirm exact configuration details. Ensure compatibility with existing N-type female interfaces. Confirm that the integrated LNA power requirements align with the host system design before finalizing procurement orders.

Antennas RF Selection Notes

Select this component when multi-constellation support including GPS, GLONASS, Galileo, and BeiDou is required. The integrated LNA makes it suitable for applications demanding high sensitivity. Verify that the base mount style fits the physical installation constraints and that the 1.5845GHz center frequency matches the target system specifications.

Antennas RF Part Context

This model belongs to the GNSS1-TMG-26N series from Amphenol PCTEL. It is part of their portfolio of RF antennas tailored for navigation and timing applications. The series focuses on providing reliable performance across various global satellite networks using standardized connectors and robust mounting styles.

Antennas RF Replacement Considerations

The GNSS1-TMG-26NMS is a related variant within the same series. Verify if the mechanical mounting differences between the MS and SCL suffixes impact the specific installation requirements.
