HC2LP-R47-R

$5.72

Description：FIXED IND 470NH 52.9A 0.6MOHM SM
Series：HC2LP
Mfr：Eaton - Electronics Division
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e410322a62b6 Category: Fixed Inductors Brand: Eaton - Electronics Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

HC2LP-R47-R is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Eaton - Electronics Division. Its product description is FIXED IND 470NH 52.9A 0.6MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for HC2LP-R47-R

Description：FIXED IND 470NH 52.9A 0.6MOHM SM
Series：HC2LP
Mfr：Eaton - Electronics Division
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：470 nH
Tolerance：±20%
Current Rating (Amps)：52.9 A
Current - Saturation (Isat)：63.75A
Shielding：Unshielded
DC Resistance (DCR)：0.6mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：300 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.756" L x 0.756" W (19.20mm x 19.20mm)
Height - Seated (Max)：0.440" (11.18mm)
Features：-

Fixed Inductors datasheet and documents for HC2LP-R47-R

HC2LP-R47-R

Fixed Inductors Overview

The Eaton HC2LP-R47-R is a high-power surface-mount inductor from the HC2LP series. It features an unshielded ferrite core and wirewound construction, designed for robust power applications. The component provides an inductance of 520 nH with a tolerance of ±20%. It supports a saturation current of 63.75 A and a maximum DC current of 52.9 A. The maximum DC resistance is 600 uOhms. Operating temperatures range from -40 C to +125 C. Physical dimensions are 19.2 mm in length, 19.2 mm in width, and 11.18 mm in height.

Fixed Inductors Feature Summary

High saturation current capability up to 63.75 A for demanding power circuits
Unshielded design utilizing ferrite core material for high power handling
Standard SMD/SMT termination style for PCB mounting

Fixed Inductors Applications

Power electronics systems
General purpose power chokes

Fixed Inductors Procurement Notes

Verify the specific electrical parameters against the official Eaton Electronics datasheet before integration, as distributor listings may contain conflicting values such as 0.47uH versus 520nH. Confirm that the unshielded configuration aligns with your electromagnetic interference requirements. Ensure the physical footprint matches your PCB layout constraints. Check current ratings carefully to avoid thermal issues in high-load scenarios.

Fixed Inductors Selection Notes

Select this component when high current handling is critical and shielding is not required. Compare the 520 nH value against other variants in the HC2LP series if different inductance is needed. Consider the larger 19.2 mm footprint compared to shielded alternatives like the DRQ or HCM1A series. Verify that the operating temperature range meets your environmental specifications.

Fixed Inductors Part Context

This part belongs to the HC2LP series of high-power chokes manufactured by Eaton Electronics. The series focuses on unshielded, wirewound inductors with ferrite cores. These components are designed for surface mount technology and are intended for applications requiring significant current capacity without magnetic shielding constraints.
