HTST-110-01-G-D-04

Headers, Male Pins Overview

The Samtec HTST-110-01-G-D-04 is a high-temperature shrouded terminal strip designed for through-hole mounting. It features a 2.54 mm pitch and consists of two rows with ten positions each, totaling twenty contacts. The connector utilizes male pin contacts made from phosphor bronze, housed in a black liquid crystal polymer (LCP) body rated UL 94 V-0. This component supports signal and power applications within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• High-temperature LCP housing for thermal stability
• Shrouded design for secure mating alignment
• Through-hole termination for robust PCB attachment

Headers, Male Pins Applications

• Board-to-board interconnects
• Wire-to-board connections
• Signal routing in high-temperature environments

Headers, Male Pins Procurement Notes

Verify the specific suffix '04' against official datasheets to confirm tail configuration and shroud details. Ensure compatibility with mating socket strips regarding height and pitch. Confirm RoHS compliance status for the specific manufacturing batch prior to integration into regulated assemblies.

Headers, Male Pins Selection Notes

Select this part for applications requiring high-temperature resistance up to 125°C. The shrouded housing ensures proper alignment during insertion. Verify that the 2.54 mm pitch matches the target board layout. Consider the through-hole mounting style for mechanical strength compared to surface mount alternatives.

Headers, Male Pins Part Context

This component belongs to the HTST series of high-temperature shrouded terminal strips by Samtec. These connectors are engineered for demanding environments where standard materials may fail. The series offers various row counts and contact configurations to suit diverse electronic assembly requirements.
