IHLP8787MZER2R2M5A

$7.88

Description：IHLP-8787MZ-5A 2.2 20% ER E3
Series：IHLP-8787MZ-5A
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:0d99bd095876 Category: Fixed Inductors Brand: Vishay Dale

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IHLP8787MZER2R2M5A is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Vishay Dale. Its product description is IHLP-8787MZ-5A 2.2 20% ER E3. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for IHLP8787MZER2R2M5A

Description：IHLP-8787MZ-5A 2.2 20% ER E3
Series：IHLP-8787MZ-5A
Mfr：Vishay Dale
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：Metal Composite
Inductance：2.2 µH
Tolerance：±20%
Current Rating (Amps)：58 A
Current - Saturation (Isat)：48A
Shielding：Shielded
DC Resistance (DCR)：1.25mOhm Max
Q @ Freq：-
Frequency - Self Resonant：17.5MHz
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 155°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.885" L x 0.866" W (22.48mm x 22.00mm)
Height - Seated (Max)：0.512" (13.00mm)
Features：-

Fixed Inductors datasheet and documents for IHLP8787MZER2R2M5A

IHLP8787MZER2R2M5A

Fixed Inductors Overview

The Vishay Dale IHLP8787MZER2R2M5A is a shielded, molded surface-mount power inductor from the IHLP-8787MZ-5A series. It features an inductance of 2.2 µH with a tolerance of ±20%. The component has a maximum DC resistance (DCR) of 1.25 mΩ, a rated current of 58 A, and a saturation current of 49 A. It operates within a temperature range of -55°C to +155°C and holds AEC-Q200 qualification. The physical dimensions are 22.48 mm x 22.00 mm x 13.00 mm.

Fixed Inductors Feature Summary

High thermal stability for continuous operation at elevated temperatures up to +155°C
Shielded construction minimizes electromagnetic interference (EMI)
Composite core material provides high current handling capabilities

Fixed Inductors Applications

Automotive electronics systems
DC/DC converter energy storage
Point-of-load (POL) converters

Fixed Inductors Procurement Notes

Verify the specific suffix '5A' confirms the correct electrical parameters and package variant. Ensure the ordering part number matches the required inductance and current ratings exactly. Confirm that the manufacturer's standard lead time aligns with project schedules before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when high current density and robust thermal performance are required in automotive or industrial environments. The 8787MZ case size offers a balance between footprint constraints and high saturation current. Verify that the 1.25 mΩ DCR meets the efficiency requirements of the target power supply design.

Fixed Inductors Part Context

This part belongs to the IHLP-8787MZ-5A family of surface-mount power inductors designed by Vishay Dale. The series is characterized by its molded composite core technology, which supports high reliability in demanding applications. The 8787MZ form factor is specifically engineered for high-current scenarios where thermal management is critical.
