IPB100N12S305ATMA1

$2.98

Description：MOSFET N-CH 120V 100A TO263-3
Series：OptiMOS™
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:a72147955575 Category: Single FETs, MOSFETs Brand: Infineon Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IPB100N12S305ATMA1 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is MOSFET N-CH 120V 100A TO263-3. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for IPB100N12S305ATMA1

Description：MOSFET N-CH 120V 100A TO263-3
Series：OptiMOS™
Mfr：Infineon Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：120 V
Current - Continuous Drain (Id) @ 25°C：100A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：5.1mOhm @ 100A, 10V
Vgs(th) (Max) @ Id：4V @ 240µA
Gate Charge (Qg) (Max) @ Vgs：185 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：11570 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：300W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：Automotive
Qualification：AEC-Q101
Mounting Type：Surface Mount
Supplier Device Package：PG-TO263-3-1
Package / Case：TO-263-4, D2PAK (3 Leads + Tab), TO-263AA

Single FETs, MOSFETs datasheet and documents for IPB100N12S305ATMA1

IPB100N12S305ATMA1

Single FETs, MOSFETs Overview

The IPB100N12S305ATMA1 is an N-channel OptiMOS-T power MOSFET in a PG-TO263-3-2 surface-mount package. It features a drain-source voltage of 120 V and a continuous drain current of 100 A at 25 °C. The maximum on-state resistance is 4.8 mΩ, with a total gate charge of 185 nC. Power dissipation reaches 300 W, supported by a thermal resistance from junction to case of 0.5 K/W. The device operates between -55 °C and +175 °C and holds AEC-Q101 automotive qualification.

Single FETs, MOSFETs Feature Summary

Automotive-grade reliability certified under AEC-Q101 standards
Optimized for high-performance switching with low on-state resistance
Robust avalanche capability verified through 100% single-pulse testing

Single FETs, MOSFETs Applications

Automotive power distribution systems
High-efficiency DC-DC converters
Motor control applications

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering suffix ATMA1 to confirm tape-and-reel packaging requirements. Confirm that the component meets the intended environmental specifications for the target application. Ensure compatibility with standard SMD reflow profiles up to 260°C peak temperature during assembly processes.

Single FETs, MOSFETs Selection Notes

Select this component for designs requiring robust automotive-grade performance in a compact surface-mount form factor. Evaluate the thermal management strategy against the specified junction-to-case resistance. Consider the gate charge characteristics when designing drive circuits for optimal switching efficiency.

Single FETs, MOSFETs Part Context

This part belongs to the IPx100N12S3-05 family of OptiMOS-T transistors. It shares core electrical characteristics with leaded variants like IPP100N12S3-05 but utilizes a different package configuration suitable for automated surface-mount assembly processes.

Single FETs, MOSFETs Replacement Considerations

Direct pin-compatible alternatives within the same family include IPI100N12S3-05 and IPP100N12S3-05. Verify package dimensions and thermal pad configurations before substitution.
