KS DELPS1.22-TIVG-78-H3Q4-20-S

LED Indication - Discrete Overview

The KS DELPS1.22-TIVG-78-H3Q4-20-S is a single-chip red LED from the TOPLED E1608 series by ams OSRAM, designed for surface-mount technology. It features a compact 1608 (1.6 x 0.8 mm) package with a rectangular lens. The component operates at a forward current of 20 mA and a forward voltage of approximately 2.2 V. It emits light at a peak wavelength of 633 nm with a viewing angle of 120 degrees. The device is rated for an operating temperature range of -40°C to +85°C and is supplied in tape and reel packaging.

LED Indication - Discrete Feature Summary

• Compact 1608 surface-mount package design suitable for space-constrained applications
• High reliability construction within the TOPLED E1608 product line
• Wide viewing angle of 120 degrees for broad illumination coverage
• RoHS compliant manufacturing process

LED Indication - Discrete Applications

• Status indication in consumer electronics
• Instrument panel lighting
• Medical device indicators
• Automotive interior signaling

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix matches the required wavelength and binning specifications. Confirm moisture sensitivity level handling procedures are followed during storage and assembly. Ensure the reflow soldering profile aligns with the manufacturer's thermal recommendations to maintain device integrity. Check for RoHS compliance documentation if required by regional regulations.

LED Indication - Discrete Selection Notes

Select this component when a small form factor red LED is required for surface-mount assembly. Consider the 120-degree viewing angle for applications needing wide dispersion. Evaluate the 20 mA forward current requirement against system power constraints. Compare package dimensions against PCB footprint limitations to ensure mechanical compatibility.

LED Indication - Discrete Part Context

This part belongs to the TOPLED E1608 series, which represents one of the smallest low-power LED packages available. The series is known for high reliability and consistent performance across various environmental conditions. It serves as a standard solution for general-purpose indication where size and durability are critical factors.

LED Indication - Discrete Replacement Considerations

• KS DELPS1.22-TIVG-78-H3Q4

LED Indication - Discrete FAQ

What is the typical forward voltage of this red LED?

The typical forward voltage is approximately 2.2 V at a forward current of 20 mA.

Does this component support surface-mount technology?

Yes, it is designed for surface-mount device (SMD) assembly using a 2-pin flat lead configuration.
