KTD2151EUO-TR

$1.10

Description：IC REG BST PROG 80MA DL 15WLCSP
Series：-
Mfr：Kinetic Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:de795a55f850 Category: Voltage Regulators - DC DC Switching Regulators Brand: Kinetic Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

KTD2151EUO-TR is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Kinetic Technologies. Its product description is IC REG BST PROG 80MA DL 15WLCSP. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for KTD2151EUO-TR

Description：IC REG BST PROG 80MA DL 15WLCSP
Series：-
Mfr：Kinetic Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Up
Output Configuration：Positive
Topology：Boost
Output Type：Programmable
Number of Outputs：2
Voltage - Input (Min)：2.7V
Voltage - Input (Max)：5.5V
Voltage - Output (Min/Fixed)：±4V
Voltage - Output (Max)：6.3V
Current - Output：80mA
Frequency - Switching：900kHz, 1.8MHz
Synchronous Rectifier：No
Operating Temperature：-40°C ~ 85°C
Mounting Type：Surface Mount
Package / Case：15-WFBGA, WLCSP
Supplier Device Package：15-WLCSP (2.2x1.45)
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for KTD2151EUO-TR

KTD2151EUO-TR

Voltage Regulators - DC DC Switching Regulators Overview

The KTD2151EUO-TR is a programmable dual output LCD bias power supply IC manufactured by Kinetic Technologies. It operates within an input voltage range of 2.7 V to 5.5 V and supports a maximum clock frequency of 1.8 MHz. The device features a maximum power dissipation of 1.3 W and draws a maximum supply current of 1.2 mA. Designed for surface mount installation, it is housed in a WLCSP-15 package. The component functions reliably across an operating temperature range from -40°C to +85°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Provides dual output capability for LCD bias power generation
Supports programmable configuration for flexible system integration
Operates with low supply current consumption

Voltage Regulators - DC DC Switching Regulators Applications

LCD display bias voltage generation
Portable electronic devices requiring compact power solutions
Embedded systems utilizing LCD interfaces

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific ordering suffix and manufacturer part number against official Kinetic Technologies documentation before procurement. Confirm that the WLCSP-15 package dimensions align with your PCB footprint requirements. Ensure compatibility with the required input voltage range and thermal management capabilities for your specific application environment.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a compact solution for dual LCD bias generation is required. The WLCSP-15 package offers space efficiency for dense layouts. Consider the 1.8 MHz clock frequency and 1.2 mA current draw when designing power delivery networks. Verify that the -40°C to +85°C operating range meets your environmental specifications.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the Kinetic Technologies LCD driver and bias supply family. It is categorized under Driver ICs and specifically designed for LCD bias applications. The manufacturer utilizes the KTD2151 series designation for these programmable power management components intended for display driving systems.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

Consult official Kinetic Technologies substitution guides for verified alternatives. Cross-reference pinouts and electrical characteristics carefully if considering similar LCD bias ICs from other manufacturers.
