LTC3210EPD-1#TRPBF

$1.59

Description：IC LED DRV RGLTR /400MA 16QFN
Series：-
Mfr：Analog Devices Inc.
Package：Tape & Reel (TR)

SKU:94f4b6163107 Category: LED Drivers IC Brand: Analog Devices Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

LTC3210EPD-1#TRPBF is listed in the LED Driver IC range at ChipApex. The manufacturer field lists Analog Devices Inc.. Its product description is IC LED DRV RGLTR /400MA 16QFN. Review the specifications below when checking this part for your BOM.

LED Driver IC specifications for LTC3210EPD-1#TRPBF

Description：IC LED DRV RGLTR /400MA 16QFN
Series：-
Mfr：Analog Devices Inc.
Package：Tape & Reel (TR)
Type：DC DC Regulator
Topology：Switched Capacitor (Charge Pump)
Internal Switch(s)：Yes
Number of Outputs：5
Voltage - Supply (Min)：2.9V
Voltage - Supply (Max)：4.5V
Voltage - Output：-
Current - Output / Channel：25mA, 400mA
Frequency：800kHz
Dimming：-
Applications：Backlight
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：16-UFQFN Exposed Pad
Supplier Device Package：16-QFN (3x3)
Grade：-
Qualification：-

LED Driver IC datasheet and documents for LTC3210EPD-1#TRPBF

LTC3210EPD-1#TRPBF

LED Driver IC Overview

The LTC3210EPD-1#TRPBF is a regulated LED driver IC manufactured by Analog Devices Inc. It features five outputs and utilizes a switched capacitor (charge pump) topology to regulate current for LED applications. The device supports input supply voltages ranging from 2.9V to 4.5V. It provides output currents of 25mA and 400mA per channel. Operating at a switching frequency of 800kHz, it is housed in a 16-QFN (3x3) surface-mount package with an exposed pad. The component is rated for operation within a temperature range of -40°C to +85°C.

LED Driver IC Feature Summary

Integrates a charge pump DC-DC converter for LED regulation
Provides five independent regulated output channels
Supports dimming control functionality
Includes internal switches for compact design

LED Driver IC Applications

LED backlighting systems
Portable electronic display illumination
General LED lighting circuits

LED Driver IC Procurement Notes

Verify the specific suffix #TRPBF indicates tape-and-reel packaging versus #PBF tube packaging when sourcing. Confirm availability status as this part number may be discontinued or subject to limited supply constraints. Ensure the selected variant matches the required package type and operating temperature range for the target application environment.

LED Driver IC Selection Notes

Select this component for designs requiring multi-channel LED regulation without external inductors. Consider the 800kHz switching frequency for EMI management and board space optimization. Evaluate the 2.9V to 4.5V input range against the system power supply. Verify that the 16-QFN package fits the PCB footprint constraints and thermal requirements.

LED Driver IC Part Context

This part belongs to the LTC3210 series of LED drivers from Analog Devices. It is functionally similar to the LTC3210EUD-1#PBF but differs in package configuration. The series focuses on small-footprint solutions for portable devices using charge pump technology to drive multiple LEDs efficiently.
