M22-2030346

Headers, Male Pins Overview

The Harwin M22-2030346 is a single-row pin header connector featuring a 2.00 mm pitch and three positions. Designed for through-hole mounting, it utilizes a right-angle configuration to facilitate compact circuit board layouts. The male pins are gold-plated to ensure reliable signal transmission and corrosion resistance in demanding environments. Constructed with a black nylon housing, this component belongs to the M22 series, which is engineered for robust performance in space-constrained electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for efficient PCB routing
• Gold-plated contacts for enhanced conductivity and durability
• Compact single-row layout suitable for dense applications

Headers, Male Pins Applications

• Compact electronic assemblies requiring reliable interconnects
• Space-constrained circuit board designs
• Industrial control systems needing durable connections

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm plating type and orientation. Ensure compatibility with mating sockets within the M22 series. Check for RoHS compliance status via the manufacturer's latest datasheet before integration into regulated projects.

Headers, Male Pins Selection Notes

Select this model when a right-angle, single-row connection is required with a 2mm pitch. Consider the gold plating for superior contact reliability compared to tin variants. Evaluate the through-hole mounting style against surface-mount alternatives based on mechanical stress requirements.

Headers, Male Pins Part Context

This component is part of the Harwin M22 series, known for its high-density rectangular connectors. The series supports various configurations including different row counts, pitches, and termination styles, catering to diverse industrial and consumer electronics needs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other M22 series headers with matching 2mm pitch and 3-position count. Verify that alternative parts maintain the same right-angle orientation and through-hole termination method to ensure mechanical fit.
