M22-2411046

Headers, Male Pins Overview

The M22-2411046 is a 10+10 way pin header from the Harwin M22 series, designed for board-to-board or cable connections. It features a 2 mm (0.079 in) pitch with two rows of positions. The connector utilizes a right-angle through-hole mounting style and includes tin-plated contacts. Key electrical specifications include a dielectric withstand voltage of 500VAC and a contact resistance of 20 mΩ. The unit supports 500 mating cycles and operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for PCB integration
• Tin-plated square pin contacts ensuring reliable conductivity
• Push-pull locking mechanism for secure connection retention

Headers, Male Pins Applications

• Industrial equipment control systems
• Data collection hardware interfaces
• Portable test and measurement devices

Headers, Male Pins Procurement Notes

Verify component authenticity by cross-referencing the manufacturer part number against official Harwin documentation. Confirm RoHS compliance status via the specific datasheet provided by the supplier. Check for obsolescence notifications as this component may be subject to discontinuation. Ensure the right-angle orientation matches the design requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 20-position dual-row header with a 2 mm pitch is required. The right-angle form factor suits space-constrained vertical PCB layouts. Verify that the 500VAC dielectric rating meets system safety standards. Consider the 2A current rating per contact for load calculations. Ensure the tin plating aligns with solderability and corrosion resistance needs.

Headers, Male Pins Part Context

This part belongs to the M22 series of high-reliability connectors manufactured by Harwin Inc. The series is characterized by robust construction suitable for demanding environments. The M22-2411046 specifically represents a 10+10 position variant within this lineup, offering a balance of density and mechanical stability for industrial applications.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. As the component is marked as obsolete, alternative solutions require manual evaluation of compatible headers with matching 2 mm pitch, 20 positions, and right-angle through-hole mounting characteristics.
