M22-2530546

Headers, Male Pins Overview

The M22-2530546 is a Harwin M22 series single-row male pin header with a 2mm pitch. It features 5 positions, through-hole solder termination, and straight orientation. The connector utilizes phosphor bronze contacts with tin plating and a black polyamide (PA6T) insulator rated UL94 V-0. Operating temperature ranges from -40°C to 105°C.

Headers, Male Pins Feature Summary

• Designed for high-density board-to-board interconnections
• Compatible with standard surface mount reflow processes
• Features durable tin-plated double-beam contacts

Headers, Male Pins Applications

• Industrial control systems
• Automotive electronics
• Consumer devices

Headers, Male Pins Procurement Notes

This component is officially obsolete and no longer manufactured by Harwin Inc. Procurement should focus on identifying verified substitute part numbers or alternative series components that meet the required electrical and mechanical specifications. Verify compatibility with existing PCB footprints before sourcing replacements.

Headers, Male Pins Selection Notes

Select replacement connectors based on matching 2mm pitch, single-row configuration, and 5-position count. Ensure the substitute supports through-hole mounting and maintains similar current ratings and temperature tolerances. Confirm that contact materials and plating are suitable for the intended application environment.

Headers, Male Pins Part Context

The M22 series represents Harwin's industrial standard socket range, designed for compact PCB applications. This specific model belongs to the male pin header subset, offering reliable connectivity in space-constrained environments while maintaining robust mechanical stability.

Headers, Male Pins Replacement Considerations

M22-2530546 is obsolete. Consider substitutes such as M22-2530542 or other compatible 5-position 2mm pitch headers from the same manufacturer or equivalent third-party suppliers.
