M22-2530646

Headers, Male Pins Overview

The M22-2530646 is a vertical pin header connector from the Harwin M22 series, designed for through-hole mounting on printed circuit boards. It features a 6-position configuration with a 2 mm (0.079 inch) pitch. The connector utilizes tin-plated contacts and is constructed with a black polyamide insulation material rated UL94 V-0. This component supports board-to-board or cable applications and operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Vertical pin header design for reliable through-hole PCB integration
• Tin-plated phosphor bronze contacts for corrosion resistance
• UL94 V-0 rated black polyamide insulation for flame retardancy

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Cable-to-board assembly applications
• General electronic equipment internal wiring

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating type and termination style. Ensure compatibility with mating socket connectors in the same M22 series family. Confirm that the 2 mm pitch matches the target PCB footprint requirements. Check for RoHS compliance status if required by project specifications.

Headers, Male Pins Selection Notes

Select this part for applications requiring a low-profile, vertical header with a standard 2 mm pitch. Consider the tin plating for general-purpose use where gold plating is not strictly necessary. Evaluate the 6-position count against signal routing needs. Ensure the through-hole mounting method aligns with the manufacturing process capabilities.

Headers, Male Pins Part Context

This component belongs to the M22 series of rectangular connectors manufactured by Harwin Inc. The series is characterized by its compact form factor and versatile mounting options. The M22-2530646 specifically represents a horizontal orientation variant within the broader product line, offering standardized spacing for dense circuit layouts.

Headers, Male Pins Replacement Considerations

M22-2530646 is a discontinued product. Verify availability of current equivalents such as M22-253xxxxxx variants with updated plating or packaging. Cross-reference with other 2mm pitch headers from different manufacturers if supply chain continuity is critical.
