M22-2540546

Headers, Male Pins Overview

The Harwin M22-2540546 is a right-angle through-hole pin header from the M22 series, designed for board-to-board applications. It features a 2.00 mm pitch with 10 positions arranged in a single row. The connector utilizes phosphor bronze contacts with gold plating and a nylon housing rated UL 94 V-0. It operates within a temperature range of -40°C to +105°C and supports a current rating of 1 A per contact at 650 VAC.

Headers, Male Pins Feature Summary

• Right-angle configuration facilitates compact PCB layout integration
• Gold-plated phosphor bronze contacts ensure reliable electrical performance
• Nylon insulation housing provides thermal stability and flame resistance

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific suffix code against official datasheets to confirm orientation and contact count. Ensure compatibility with mating connectors regarding pitch and row configuration. Check RoHS compliance status for regulatory requirements. Confirm lead time availability as manufacturing schedules may vary. Validate that the right-angle design meets spatial constraints on the target PCB.

Headers, Male Pins Selection Notes

Select this component when a right-angle connection is required for space-constrained designs. The 2.00 mm pitch offers higher density compared to standard 2.54 mm options. Verify that the 1 A current rating suffices for the application load. Ensure the through-hole mounting method aligns with the assembly process capabilities.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which specializes in 2.00 mm pitch connectors. The series includes various configurations such as vertical headers, shrouded housings, and cable connectors. The M22 line is engineered for high reliability in demanding industrial environments.

Headers, Male Pins Replacement Considerations

No direct substitute part numbers are publicly confirmed for this specific model. Evaluate other Harwin M22 series variants with matching pitch and position counts if exact replacements are unavailable.
