M22-5300505R

Headers, Male Pins Overview

The M22-5300505R is a double-row, unshrouded male pin header from the Harwin M22 series. It features a 2 mm (0.079 inch) pitch and contains 10 contacts arranged in a 5+5 configuration. The connector utilizes surface mount straight termination for board-to-board applications. Housing includes location pegs to assist with pick-and-place assembly. Contact material is phosphor bronze.

Headers, Male Pins Feature Summary

• Double-row unshrouded male pin header design
• Surface mount straight termination with location pegs
• Phosphor bronze contact material

Headers, Male Pins Applications

• Board-to-board interconnections
• Pick-and-place automated assembly
• General electronic circuit connections

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status via official datasheets. Check for obsolescence notifications as availability may vary. Ensure storage conditions meet manufacturer specifications to maintain connector integrity prior to installation.

Headers, Male Pins Selection Notes

Select this component for applications requiring vertical surface mount headers with a 2 mm pitch. The unshrouded design suits space-constrained layouts. Location pegs facilitate precise placement during SMT processes. Verify mating connector compatibility and current ratings before integration into the final design.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series of connectors, known for high-density interconnect solutions. The M22 series offers various configurations including through-hole and surface mount options. This specific model represents a standard double-row male header variant within that product family.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Harwin technical support for equivalent alternatives if this specific part number is unavailable or discontinued.
