M22-5430805

Headers, Male Pins Overview

The M22-5430805 is a surface mount board-to-board header from the Harwin M22 series. It features an 8-position, single-row configuration with a 2mm pitch. The connector utilizes gold-plated phosphor bronze contacts and a black polyamide (PA6T) insulator. Designed for vertical installation, it supports a rated current of 1A per contact and operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly
• Gold-plated phosphor bronze contacts for reliable conductivity
• High-temperature resistant PA6T insulation material

Headers, Male Pins Applications

• Industrial control systems
• Medical electronic equipment
• Metering and measurement devices

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm exact plating thickness and reel packaging details. Ensure compatibility with standard SMT reflow profiles. Confirm that the selected variant matches the required board thickness and mating connector specifications for the target application.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount solution is required for high-density interconnects. The 2mm pitch offers a balance between signal density and manufacturing tolerance. Verify that the mating socket provides sufficient retention force for the intended mechanical environment.

Headers, Male Pins Part Context

This part belongs to the M22 family of connectors, which are engineered for harsh environments including aviation, defense, and space applications. The series is characterized by robust mechanical performance and reliability under severe vibration and shock conditions.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include M22-7140805 and M22-6550805. Verify pin count and orientation compatibility before substitution.
