M50-3201445

Description：CONN RCPT 28P 0.05 GOLD PCB R/A
Series：Archer M50
Mfr：Harwin Inc.
Package：Tube

SKU:18b21e80c1f7 Category: Headers, Receptacles, Female Sockets Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M50-3201445 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN RCPT 28P 0.05 GOLD PCB R/A. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for M50-3201445

Description：CONN RCPT 28P 0.05 GOLD PCB R/A
Series：Archer M50
Mfr：Harwin Inc.
Package：Tube
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board or Cable
Number of Positions：28
Number of Positions Loaded：All
Pitch - Mating：0.050" (1.27mm)
Number of Rows：2
Row Spacing - Mating：0.050" (1.27mm)
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Insulation Color：Black
Insulation Height：0.136" (3.46mm)
Contact Length - Post：0.094" (2.40mm)
Operating Temperature：-40°C ~ 105°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Gold
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：1A
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for M50-3201445

M50-3201445

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3201445 is a side-entry socket assembly from the Archer M50 series, designed for board-to-board interconnections. It features a 1.27 mm pitch and a dual-in-line configuration with 14 positions (2 rows of 7). The connector utilizes gold-plated phosphor bronze contacts housed in a black polyamide body. Rated for 1 A current and 150 V voltage, it operates within a temperature range of -40°C to +105°C. The unit has a height of 3.60 mm and meets UL 94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

Side-entry mating interface facilitates vertical PCB stacking
Gold-plated contacts ensure reliable signal transmission
Compact SMT footprint supports high-density layouts

Headers, Receptacles, Female Sockets Applications

Vertical board-to-board connections
High-density electronic assemblies
Industrial control systems

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm mechanical orientation and contact plating specifications. Ensure compatibility with mating header part numbers before procurement. Confirm RoHS compliance status through the manufacturer's latest datasheet or component specification sheet.

Headers, Receptacles, Female Sockets Selection Notes

Select this component for applications requiring vertical stacking with limited lateral space. The side-entry design accommodates tight clearances between stacked boards. Verify that the 1.27 mm pitch aligns with the target PCB land pattern and mating connector requirements.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Harwin Archer M50 series, which provides high-reliability interconnect solutions. The M50 family offers various configurations including straight and angled headers, sockets, and IDC connectors. This specific model represents the side-entry variant optimized for compact vertical integration.
