M50-4300645

Headers, Receptacles, Female Sockets Overview

The Harwin M50-4300645 is a surface-mount receptacle connector from the Archer M50 series. It features a 12-position, single-row configuration with a 1.27 mm (0.05 in) pitch. The contacts are female sockets plated with gold, fabricated from phosphor bronze to ensure reliable signal transmission. Designed for vertical installation on printed circuit boards, this component utilizes a solder termination method suitable for automated assembly processes. The housing is constructed from black liquid crystal polymer (LCP), providing high thermal stability and mechanical strength. It operates within a temperature range of -40°C to +105°C and meets UL 94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• Surface-mount design optimized for automated pick-and-place manufacturing
• Gold-plated phosphor bronze contacts for enhanced conductivity and corrosion resistance
• High-temperature LCP housing ensuring structural integrity under thermal stress
• Vertical orientation facilitating compact board-to-board interconnections

Headers, Receptacles, Female Sockets Applications

• Compact consumer electronics requiring dense I/O connections
• Industrial control systems needing reliable signal interfaces
• Automotive electronic modules with space constraints
• Medical device instrumentation requiring stable connectivity

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required contact count and row configuration before ordering. Confirm that the surface-mount footprint aligns with the target PCB layout specifications. Ensure compatibility with standard reflow soldering profiles used in your production line. Check for any specific handling requirements related to the moisture sensitivity level of the LCP material. Validate that the voltage and current ratings meet the operational demands of the intended circuit application.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, high-density connection is required for signal-level applications. The 1.27 mm pitch allows for significant pin density within limited board areas. Consider the gold plating for environments where oxidation resistance is critical. The single-row format simplifies routing compared to dual-row alternatives. Evaluate the thermal performance of the LCP material against the operating conditions of the final assembly to ensure long-term reliability.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Archer M50 series by Harwin, a line known for precision micro-connectors. The series offers various configurations including headers, receptacles, and IDC options. The M50-4300645 specifically addresses needs for small-form-factor electronics. Its design supports modern manufacturing techniques while maintaining robust electrical performance. The series is widely utilized in industries demanding high reliability and miniaturization.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 1.27 mm pitch, 12-position count, and surface-mount termination. Verify that alternative components share the same female socket contact type and gold plating specification. Ensure the replacement housing material provides equivalent thermal and mechanical properties. Cross-reference the mounting footprint dimensions to guarantee PCB compatibility without redesign.
