M50-4303045

Headers, Receptacles, Female Sockets Overview

The Harwin M50-4303045 is a board-to-board receptacle connector from the Archer M50 series. It features a dual-row configuration with 60 positions (30+30) and a 1.27mm pitch. Designed for surface-mount technology (SMT), it utilizes gold-plated contacts housed in a black polymer body. The connector operates within a temperature range of -40°C to +105°C and meets UL 94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row edge-type architecture for high-density PCB interconnects
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Surface-mount design facilitates automated assembly processes

Headers, Receptacles, Female Sockets Applications

• General-purpose board-to-board interconnects
• High-density electronic assemblies requiring robust connections
• Industrial control systems utilizing surface-mount technologies

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Harwin documentation to confirm current availability status and lifecycle stage. Ensure compatibility with mating header specifications, including row spacing and contact alignment, prior to procurement. Check for any recent manufacturing updates or packaging variations that may affect installation procedures.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 60-position SMT receptacle with 1.27mm pitch is required. Consider the dual-row layout for space-constrained designs. Verify that the mating header matches the Archer M50 series specifications to ensure proper engagement and mechanical stability during operation.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Archer M50 series by Harwin Inc., known for compact board-to-board solutions. The M50-4303045 variant specifically addresses applications needing 60 contacts in a surface-mount format. It complements other series components offering varying pin counts and mounting styles.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Harwin resources for confirmed substitute part numbers. Cross-reference mating headers to ensure mechanical and electrical compatibility before considering alternative components.
