M52-040000P2045

$2.93

Description：CONN HDR 1.27MM 20POS
Series：Archer M52
Mfr：Harwin Inc.
Package：Bulk

SKU:16bca040731d Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M52-040000P2045 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HDR 1.27MM 20POS. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M52-040000P2045

Description：CONN HDR 1.27MM 20POS
Series：Archer M52
Mfr：Harwin Inc.
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.050" (1.27mm)
Number of Positions：20
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.157" (4.00mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.098" (2.50mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Gold
Contact Material：Brass
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A
Voltage Rating：-

Headers, Male Pins datasheet and documents for M52-040000P2045

M52-040000P2045

Headers, Male Pins Overview

The Harwin M52-040000P2045 is a 20-position, single-row pin header from the Archer M52 series. It features a 1.27 mm pitch and vertical orientation for board-to-board connections. The connector utilizes gold-plated brass contacts and a nylon housing. Designed for surface mount technology (SMT), it supports a rated current of 1A. The operating temperature range spans from -40°C to 105°C, with a tail pin length of 2.3 mm.

Headers, Male Pins Feature Summary

Vertical surface mount design for direct PCB integration
Gold-plated brass contacts ensure reliable signal transmission
Nylon housing provides structural stability and insulation

Headers, Male Pins Applications

Board-to-board interconnections in compact electronic modules
High-density circuit board assemblies requiring precise alignment
Industrial control systems operating within specified thermal limits

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm contact count, pitch, and mounting style. Ensure compatibility with existing PCB footprint designs and soldering profiles. Cross-reference technical datasheets for mechanical dimensions and environmental ratings before procurement to prevent integration errors.

Headers, Male Pins Selection Notes

Select this component for applications requiring a single-row, vertical header with a 1.27 mm pitch. Consider the 1A current rating and -40°C to 105°C temperature range for operational suitability. Evaluate the surface mount requirement and unshrouded design against spatial constraints and mating connector specifications.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer M52 series, which offers high-density PCB connectors. The series is characterized by its 1.27 mm pitch and robust construction suitable for demanding environments. The M52-040000P2045 specifically represents the 20-position variant within this lineup.
