MAL211690086E3

MAL211690086E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 22UF 20% 50V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL211690086E3

• Description：CAP ALUM 22UF 20% 50V RADIAL TH
• Series：116 RLL
• Mfr：Vishay Beyschlag/Draloric/BC Components
• Package：Tape & Box (TB)
• Capacitance：22 µF
• Tolerance：±20%
• Voltage - Rated：50 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 105°C
• Operating Temperature：-55°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：Automotive
• Ripple Current @ Low Frequency：119.7 mA @ 100 Hz
• Ripple Current @ High Frequency：-
• Lead Spacing：0.197" (5.00mm)
• Size / Dimension：0.323" Dia (8.20mm)
• Height - Seated (Max)：0.472" (12.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：900 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for MAL211690086E3
