MND-06CZER33M-XB

MND-06CZER33M-XB is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 0.33UH 25A 2.53 MOHM S. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MND-06CZER33M-XB

• Description：FIXED IND 0.33UH 25A 2.53 MOHM S
• Series：XB
• Mfr：Pulse Electronics
• Package：Tape & Reel (TR)
• Type：Molded
• Material - Core：Metal
• Inductance：330 nH
• Tolerance：±20%
• Current Rating (Amps)：25 A
• Current - Saturation (Isat)：-
• Shielding：Shielded
• DC Resistance (DCR)：2.53mOhm Max
• Q @ Freq：-
• Frequency - Self Resonant：-
• Ratings：-
• Operating Temperature：-55°C ~ 125°C
• Inductance Frequency - Test：100 kHz
• Mounting Type：Surface Mount
• Package / Case：Nonstandard
• Supplier Device Package：-
• Size / Dimension：0.157" L x 0.157" W (4.00mm x 4.00mm)
• Height - Seated (Max)：0.079" (2.00mm)
• Features：-

Fixed Inductors datasheet and documents for MND-06CZER33M-XB
