MPM-100SVI-48

MPM-100SVI-48 is listed in the AC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is AC/DC MODULE ,100W, 48V OUT. Review the specifications below when checking this part for your BOM.

AC DC Converters specifications for MPM-100SVI-48

• Description：AC/DC MODULE ,100W, 48V OUT
• Series：MPM-100SVI (100W)
• Mfr：MicroPower Direct
• Package：Box
• Type：Open Frame
• Number of Outputs：1
• Voltage - Input：90 ~ 264 VAC, 120 ~ 370 VDC
• Voltage - Output 1：48V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2.083A
• Applications：Industrial, ITE (Commercial)
• Features：Universal Input
• Operating Temperature：-40°C ~ 85°C
• Efficiency：-
• Mounting Type：Chassis Mount
• Package / Case：-
• Size / Dimension：3.50" L x 2.50" W x 1.08" H (88.9mm x 63.5mm x 27.4mm)
• Approval Agency：CE, cURus, UKCA
• Standard Number：62368-1
• Power (Watts)：-

AC DC Converters datasheet and documents for MPM-100SVI-48
