MPXV53GC7U

Pressure Sensors Transducers Overview

The MPXV53GC7U is a 50 kPa uncompensated silicon pressure sensor manufactured by NXP Semiconductors. It operates with a 5V supply and features an axial port size of 3.17 mm. The device draws an operating supply current of 6 mA. Packaged in a Surface Mount (SOP) 8 configuration, it functions as a board mount pressure sensor designed for gauge pressure measurement applications.

Pressure Sensors Transducers Feature Summary

• Utilizes uncompensated silicon technology for pressure sensing
• Designed for board mount integration
• Features an axial port configuration

Pressure Sensors Transducers Applications

• Gauge pressure measurement systems
• Board mount electronic assemblies
• Industrial sensor interfaces

Pressure Sensors Transducers Procurement Notes

Verify the specific suffix 'GC7U' against official NXP documentation to confirm package type and port orientation. Ensure the required 50 kPa range aligns with system requirements. Confirm that the uncompensated nature of the sensor meets application accuracy needs without additional signal conditioning.

Pressure Sensors Transducers Selection Notes

Select this component when a 50 kPa gauge pressure range is required for board-mounted applications. Consider the SOP 8 package constraints and the need for external compensation if high precision is necessary. Verify compatibility with the 5V supply voltage and 6 mA current draw limits.

Pressure Sensors Transducers Part Context

This part belongs to the MPX series of silicon pressure sensors from NXP Semiconductors. These devices are engineered for reliable pressure detection in various industrial and consumer electronics environments, offering a compact solution for integrating pressure monitoring into printed circuit boards.

Pressure Sensors Transducers Replacement Considerations

Consult official NXP substitution guides for verified alternatives. Generic cross-references may not match the specific axial port or SOP 8 package characteristics required for this model.
