MXJEAFC20M0

Crystals Overview

The Meritek MXJEAFC20M0 is a parallel fundamental quartz crystal operating at a nominal frequency of 20 MHz. It utilizes the HC49S package format and features a load capacitance of 18 pF with an equivalent series resistance of 40 Ohms. The component offers frequency stability options of ±10 ppm or ±20 ppm and operates within a temperature range of -20°C to +70°C. It is lead-free and RoHS compliant, designed for standard through-hole mounting applications requiring precise timing signals.

Crystals Feature Summary

• Parallel fundamental resonance operation
• HC49S through-hole package configuration
• Lead-free and RoHS compliant construction

Crystals Applications

• Microcontroller clock sources
• Communication equipment timing
• General-purpose oscillator circuits

Crystals Procurement Notes

Verify the specific frequency tolerance (±10 ppm or ±20 ppm) required for your design, as datasheets may list both variants under similar part numbering conventions. Confirm the exact load capacitance matches your oscillator circuit requirements. Ensure the HC49S package dimensions align with your PCB footprint constraints before finalizing procurement.

Crystals Selection Notes

Select this component when a standard HC49S form factor is required for 20 MHz timing. Consider the ±10 ppm or ±20 ppm stability based on system precision needs. Verify that the -20°C to +70°C operating range meets environmental specifications. Ensure the 18 pF load capacitance is compatible with the host oscillator design.

Crystals Part Context

This part belongs to Meritek's quartz crystal portfolio, specifically the HC49S series. These components are widely used in consumer electronics and industrial control systems where reliable, low-cost timing solutions are necessary. The MXJEAFC20M0 represents a standard frequency option within this extensive passive component family.

Crystals Replacement Considerations

Direct substitutes include other manufacturers' HC49S 20 MHz crystals with matching 18 pF load capacitance and similar stability ratings. Verify package compatibility and electrical parameters before substitution.
