NSR006A0X4Z

NSR006A0X4Z is listed in the DC DC Converters range at ChipApex. The manufacturer field lists OmniOn Power™. Its product description is DC DC CONVERTER 0.6-6V 36W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for NSR006A0X4Z

• Description：DC DC CONVERTER 0.6-6V 36W
• Series：Naos Raptor
• Mfr：OmniOn Power™
• Package：Tray
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：14V
• Voltage - Output 1：0.6 ~ 6V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：6A
• Power (Watts)：36 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OTP, UVLO
• Operating Temperature：-40°C ~ 85°C
• Efficiency：95.10%
• Mounting Type：Through Hole
• Package / Case：5-SIP Module
• Size / Dimension：0.41" L x 0.31" W x 0.65" H (10.4mm x 7.9mm x 16.5mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for NSR006A0X4Z
