OUAZ-SS-112L,900

OUAZ-SS-112L,900 is listed in the Signal Relays, Up To 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY TELECOM SPDT 1A 12V. Review the specifications below when checking this part for your BOM.

Signal Relays, Up To 2 Amps specifications for OUAZ-SS-112L,900

• Description：RELAY TELECOM SPDT 1A 12V
• Series：OUAZ, OEG
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Tube
• Mounting Type：Through Hole
• Coil Voltage：12VDC
• Contact Form：SPDT (1 Form C)
• Contact Rating (Current)：1:00 AM
• Switching Voltage：120VAC, 24VDC - Max
• Load - Max Switching：120VA, 24W
• Coil Current：17 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin
• Seal Rating：Sealed - Flux Protection
• Coil Insulation：-
• Must Operate Voltage：9 VDC
• Must Release Voltage：1.2 VDC
• Operate Time：10 ms
• Release Time：7 ms
• Operating Temperature：-30°C ~ 70°C
• Contact Material：Silver Palladium (AgPd), Gold (Au)
• Approval Agency：-
• Relay Type：Telecom
• Grade：-
• Qualification：-

Signal Relays, Up To 2 Amps datasheet and documents for OUAZ-SS-112L,900
