PE7212-6

Attenuators Overview

The PE7212-6 is a fixed 6 dB attenuator manufactured by Pasternack. It operates within a frequency range of 0 Hz to 6 GHz and features a 50 Ohm impedance. The device utilizes an in-line, resistive PI attenuator pad design. It is constructed with 7/16 DIN female connectors on both ends. The unit is rated for 100 Watts of power handling capacity. The housing is made of black anodized aluminum.

Attenuators Feature Summary

• Fixed 6 dB attenuation value
• Resistive PI attenuator pad design
• 7/16 DIN female to female connector configuration

Attenuators Applications

• Signal level reduction in RF systems
• Impedance matching applications
• Test and measurement setups requiring precise attenuation

Attenuators Procurement Notes

Verify the specific connector type and power rating against your system requirements before procurement. Confirm that the 7/16 DIN female interface matches your existing infrastructure. Ensure the 100 Watt power handling capability exceeds your operational signal levels to prevent damage. Check for RoHS compliance if required by your manufacturing standards. Review the datasheet for detailed mechanical dimensions and mounting specifications.

Attenuators Selection Notes

Select this component when a fixed 6 dB attenuation is required at frequencies up to 6 GHz. The 50 Ohm impedance ensures compatibility with standard RF transmission lines. The 7/16 DIN connector size supports high-power applications up to 100 Watts. Consider the physical size and weight constraints of the black anodized aluminum housing during integration.

Attenuators Part Context

This model belongs to Pasternack's line of coaxial RF attenuators. These components are designed for reliable signal control in microwave and radio frequency circuits. The series offers various attenuation values and connector options to suit different system architectures.

Attenuators Replacement Considerations

Direct substitutes include other 6 dB fixed attenuators from Pasternack with identical 7/16 DIN female interfaces and similar power ratings. Verify that any replacement maintains the 0 Hz to 6 GHz frequency range and 50 Ohm impedance specification.
