RL104-N-2-2-BP

Single Diodes Overview

The RL104-N-2-2-BP is a standard recovery rectifier manufactured by Micro Commercial Components (MCC). It belongs to the RL104GP series and features a single silicon element with a maximum average forward rectified current of 1.0 Ampere. The device supports reverse voltage ratings ranging from 50 Volts to 1000 Volts, depending on the specific suffix variant. It utilizes an axial leaded plastic package designed for through-hole mounting. Key electrical characteristics include a low forward voltage drop and high surge current capability, ensuring reliable performance in general-purpose rectification applications.

Single Diodes Feature Summary

• Standard recovery design optimized for general-purpose rectification tasks
• Metalurgically bonded construction for enhanced structural integrity
• Low forward voltage drop to minimize power loss during operation
• High surge current capability to withstand transient load conditions

Single Diodes Applications

• General-purpose AC to DC conversion circuits
• Power supply input rectification stages
• Battery charging circuit protection
• Low-frequency signal demodulation

Single Diodes Procurement Notes

Verify the exact reverse voltage rating required for your application, as the RL104 series spans multiple voltage classes. Confirm that the axial lead configuration matches your PCB footprint requirements. Check for RoHS compliance status if environmental regulations apply to your manufacturing process. Ensure the operating temperature range meets your system's thermal specifications.

Single Diodes Selection Notes

Select this component when a robust, cost-effective solution for moderate current rectification is needed. The 1A current rating suits small to medium power supplies. Consider the reverse voltage margin carefully, as the series covers up to 1000V. The axial package facilitates easy manual assembly or wave soldering processes compared to surface-mount alternatives.

Single Diodes Part Context

This part falls under the MCC RL104 family of 1 Ampere silicon rectifiers. These components are widely used in consumer electronics and industrial control systems where reliability and low cost are prioritized. The series offers various voltage options to accommodate different input line voltages and transformer secondary outputs.

Single Diodes Replacement Considerations

Compatible substitutes include the generic 1N400x series diodes for lower voltage applications and other 1A standard recovery rectifiers from manufacturers like Vishay or STMicroelectronics. Ensure any replacement maintains the same axial package dimensions and current handling capabilities.
