S6E2HE4G0AGB3000A

Microcontrollers Overview

The Infineon S6E2HE4G0AGB3000A is a 32-bit microcontroller from the FM4 S6E2H series, based on the ARM Cortex-M4F core. It operates at frequencies up to 160 MHz and includes an integrated floating-point unit (FPU). The device features 256 Kbytes of MainFlash memory and 32 Kbytes of WorkFlash. On-chip SRAM totals 32 Kbytes, divided into SRAM0 (16 Kbytes), SRAM1 (8 Kbytes), and SRAM2 (8 Kbytes). It supports a wide voltage range of 2.7 V to 5.5 V.

Microcontrollers Feature Summary

• Integrated ARM Cortex-M4F processor with FPU and DSP instruction support for high-performance computing.
• Comprehensive peripheral set including CAN interfaces, multi-function serial interfaces, and DMA controllers.
• Advanced motor control capabilities via Multi-function Timers and Quadrature Position/Revolution Counters.
• Robust security and reliability features including Flash Accelerator, MPU, and multiple watchdog timers.

Microcontrollers Applications

• Servo motor speed control systems
• Industrial automation controllers
• Battery-powered equipment requiring low-power modes
• Automotive electronic control units

Microcontrollers Procurement Notes

Verify the specific ordering suffix G0A corresponds to the FBGA-121 package variant when sourcing. Confirm that the component meets RoHS compliance requirements for your manufacturing process. Ensure that ESD handling precautions are strictly followed during assembly due to moisture sensitivity levels. Cross-reference the datasheet revision *G to ensure alignment with current design specifications.

Microcontrollers Selection Notes

Select this model when a balance of moderate flash capacity and extensive I/O connectivity is required. The inclusion of both hardware and software watchdogs suits safety-critical applications. Consider the external bus interface if expansion beyond internal memory is necessary. Evaluate pin availability against the 120-pin package constraints for complex peripheral routing.

Microcontrollers Part Context

This component belongs to the Cypress FM4 family, now part of Infineon's portfolio. The S6E2H series targets cost-sensitive yet performance-demanding embedded applications. It shares architectural similarities with other FM4 devices but offers specific memory and peripheral configurations tailored for motor control and general-purpose industrial use cases.

Microcontrollers Replacement Considerations

Direct substitutes within the same series include S6E2HG4G0AGB3000A or S6E2H44G0AGB3000A, depending on whether higher flash capacity or different pin counts are acceptable. Verify compatibility with existing firmware as peripheral availability may vary across the S6E2H lineup.
