S6J336CHTBSE20000

Microcontrollers Overview

The Infineon S6J336CHTBSE20000 is an automotive microcontroller from the TRAVEO T1G series, built on a 40-nm CMOS process. It features a 32-bit ARM Cortex-R5F CPU core operating at up to 132 MHz with an internal flash memory access speed of 80 MHz. The device includes 2,112 KB of TC-Flash and 112 KB of Work-Flash, alongside 128 KB of TC-RAM and 128 KB of System-RAM (including backup areas). It supports 5 V or 3.3 V power supplies and offers packages such as LQFP-144 and TEQFP-176. Designed for ASIL-B compliance per ISO 26262, it integrates CAN FD, Secure Hardware Extension (SHE), and operates within a temperature range of -40 °C to 105 °C.

Microcontrollers Feature Summary

• Supports ASIL-B safety specifications for automotive applications
• Integrates Secure Hardware Extension (SHE) for security
• Includes CAN FD controllers and multi-function serial interfaces
• Features LCD controller and sound processing capabilities

Microcontrollers Applications

• Automotive cluster applications
• General meter control systems
• Driver interface connections for speed, tachometer, temperature, and fuel meters

Microcontrollers Procurement Notes

Verify the specific ordering suffix against official documentation to confirm package type, pin count, and memory configuration. Ensure compatibility with required power supply voltages and environmental operating ranges before integration into designs.

Microcontrollers Selection Notes

Select this component for applications requiring ASIL-B functional safety certification and secure hardware extensions. Consider the available package options and memory sizes to match system requirements for automotive cluster and metering applications.

Microcontrollers Part Context

This part belongs to the S6J3360/S6J3370 series of the TRAVEO T1G family. Originally developed by Cypress Semiconductor, these devices are now part of the Infineon portfolio. The series targets automotive electronics requiring high reliability and safety standards.

Microcontrollers Replacement Considerations

Consult official datasheets for cross-referencing. Verify that any substitute maintains identical pinout, memory architecture, and safety certification levels for direct replacement in existing designs.
