SL 10 SMD 078 19 Z

Headers, Male Pins Overview

The SL 10 SMD 078 19 Z is a surface mount pin header manufactured by Fischer Elektronik. It features a single row with 19 contacts and a 2.54 mm (0.100 inch) pitch. The connector is designed for board-to-board or wire-to-board applications using a straight orientation. Official documentation indicates variants within this series support specific plating options, including gold over nickel (Au/Ni) and tin (Sn), with operating temperature ranges typically spanning from -40°C to +163°C.

Headers, Male Pins Feature Summary

• Surface mount design compatible with pick-and-place assembly processes
• Single row configuration with standardized 2.54 mm contact spacing
• Available in various contact surface finishes including gold and tin plating

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic circuit assembly

Headers, Male Pins Procurement Notes

Verify the complete part number suffix, as Fischer Elektronik uses specific codes to denote contact count, plating type, and packaging format. Confirm that the required variant matches the intended surface finish and reel specifications. Ensure compatibility with standard SMD reflow profiles and check for any specific handling requirements associated with the chosen packaging method.

Headers, Male Pins Selection Notes

Select this component based on the requirement for a 19-position surface mount header with a 2.54 mm pitch. Consider the necessary contact material and plating thickness for the application environment. Verify that the straight form factor fits the mechanical constraints of the PCB layout and mating connector interface.

Headers, Male Pins Part Context

This part belongs to the SL 10 SMD 078 series of pin headers from Fischer Elektronik. The series offers various contact counts and plating options to suit different manufacturing needs. These connectors are characterized by their reliability in surface mount technology environments and are widely used in industrial and consumer electronics assemblies requiring robust electrical connections.
