SL 15 SMD 107 34 S

Headers, Male Pins Overview

The SL 15 SMD 107 34 S is a surface-mount board-to-board and wire-to-board connector header manufactured by Fischer Elektronik. It features a single row with 34 contacts and a standard pitch of 2.54 mm. The component utilizes a square pin cross-section measuring 0.635 mm to ensure reliable mechanical connection. Designed for high-reliability applications, it supports nominal currents up to 3 A and withstands test voltages of 2000 V. The insulating body is constructed from PA 4.6 GF material, providing stability across an operating temperature range of -40°C to +163°C.

Headers, Male Pins Feature Summary

• Single-row surface-mount design for compact board-to-board and wire-to-board interconnections
• Square pin geometry ensures secure mating and stable electrical contact
• High dielectric strength with 2000 V test voltage capability
• Thermally stable PA 4.6 GF insulating body suitable for extreme environments

Headers, Male Pins Applications

• Industrial control systems requiring robust surface-mount connectivity
• Consumer electronics utilizing wire-to-board interface solutions
• Automotive electronic modules demanding high thermal resistance
• Test and measurement equipment needing precise signal routing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'S' against the manufacturer's current datasheet to confirm plating type and terminal finish. Ensure the selected variant matches the required contact count of 34 positions. Cross-reference the package dimensions and mounting style to guarantee compatibility with the target PCB footprint. Confirm that the PA 4.6 GF material rating aligns with the operational thermal requirements of the final assembly.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2.54 mm pitch surface-mount header is required for high-density applications. The 34-position configuration suits interfaces needing extensive signal or power distribution within limited board space. Consider the square pin design for enhanced retention force compared to round pins. Evaluate the 2000 V test voltage rating if the application involves high-potential isolation requirements or harsh electrical environments.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL 15 SMD series, which offers various configurations in terms of row count, position numbers, and housing colors. The series provides standardized 2.54 mm pitch headers designed for automated surface-mount assembly processes. Variants within this family differ primarily in contact quantity and specific housing characteristics while maintaining consistent electrical ratings and mechanical interface standards.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 34-position count, 2.54 mm pitch, and surface-mount form factor. Verify that alternative components support the same 3 A nominal current and 2000 V test voltage specifications. Ensure the replacement uses compatible insulating materials capable of withstanding similar thermal ranges. Check for identical pin geometry to maintain mechanical fit and contact reliability in existing assemblies.
