SL 2 154 2 Z

Headers, Male Pins Overview

The SL 2 154 2 Z is a two-row pin header connector from the Fischer Elektronik SL 2 series, designed for through-hole mounting. It features a 2.54 mm pitch and 62 positions with square contacts. The contact material is copper alloy tin-plated, providing a standard configuration with a maximum contact resistance of ≤5 mΩ. Rated at 3 A current and 250 V AC, it withstands 2000 V dielectric voltage. The insulator is made of PA 4.6 nylon (UL 94 V-0), operating between -40°C and +163°C.

Headers, Male Pins Feature Summary

• Two-row board-to-board or wire-to-board interconnection capability
• Through-hole soldering termination for secure PCB attachment
• Tin-plated copper alloy contacts ensuring low resistance performance

Headers, Male Pins Applications

• Industrial control system signal routing
• Electronic module stacking interfaces
• Test and measurement equipment connections

Headers, Male Pins Procurement Notes

Verify the specific part number suffix against the manufacturer datasheet to confirm contact plating and row count. Ensure the ordering code matches the required pole count and insulation material specifications. Cross-reference the UL certification status if flame retardancy is critical for the target application environment.

Headers, Male Pins Selection Notes

Select this component when a robust, high-current through-header is needed for dense circuit layouts. The 2.54 mm pitch ensures compatibility with standard mating connectors. Consider the thermal operating range and dielectric strength requirements before finalizing the design integration.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL 2 series, which specializes in precision-engineered pin headers. The series offers various row counts and pole configurations, utilizing durable PA 4.6 insulation materials suitable for demanding electronic environments and automated assembly processes.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical dimensions and electrical ratings against alternative suppliers to ensure functional equivalence.
