SL 4 152 20 Z

Headers, Male Pins Overview

The SL 4 152 20 Z is a Fischer Elektronik pin header connector from the SL 4 series. It features 20 contacts with a 2.54 mm pitch and a single row configuration. The connector utilizes bronze contact material with tin plating for reliable electrical performance. Designed for through-hole mounting, it supports a current rating of 3 A and a voltage rating of 250 V. The component is intended for industrial and electronic manufacturing applications requiring precise interconnection.

Headers, Male Pins Feature Summary

• Precision-engineered male header design
• Through-hole termination method
• Tin-plated bronze contacts

Headers, Male Pins Applications

• Industrial electronic manufacturing
• PCB interconnection systems
• Electronic equipment assembly

Headers, Male Pins Procurement Notes

Verify the specific part number SL 4 152 20 Z against official Fischer Elektronik documentation to confirm compatibility. Ensure that the tin-plated contact finish meets the required environmental standards for the application. Confirm that the through-hole mounting style aligns with the PCB layout requirements. Cross-reference the 2.54 mm pitch specification with mating connectors to guarantee proper fit and electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a 20-position male header with a 2.54 mm pitch is required. The tin-plated bronze contacts offer a balance of conductivity and cost-effectiveness for general-purpose applications. Consider the through-hole mounting option if surface-mount alternatives are not suitable for the mechanical stability needs. Verify that the 3 A current rating and 250 V voltage rating are sufficient for the target circuit parameters.

Headers, Male Pins Part Context

This component belongs to the SL 4 series of pin headers manufactured by Fischer Elektronik. The series is characterized by precision engineering for demanding industrial environments. The SL 4 152 20 Z specifically provides a 20-contact configuration, distinguishing it from other variants in the same family that may offer different pin counts or contact materials.

Headers, Male Pins Replacement Considerations

The alternative designation SL 4 152 20 G is documented as an equivalent variant within the same product range.
