SLV W 1 055 23 G

Headers, Male Pins Overview

The SLV W 1 055 23 G is a pin header manufactured by Fischer Elektronik, designed for board-to-board and wire-to-board connections. It features a 1.27 mm pitch with a single row of 23 contacts. The component utilizes a through-hole straight mounting style for secure PCB integration. Constructed with specific alloy materials and plating, it supports standard electrical ratings suitable for general electronic interconnect applications.

Headers, Male Pins Feature Summary

• Single row configuration with 23 contacts
• 1.27 mm contact pitch
• Through-hole straight mounting style

Headers, Male Pins Applications

• Board-to-board interconnects
• Wire-to-board connections
• General electronic circuit assembly

Headers, Male Pins Procurement Notes

Verify the exact part number against manufacturer documentation to ensure compatibility with mating female headers such as the BLM series. Confirm that the 1.27 mm pitch and 23-contact count match the design requirements. Check material specifications and plating types if environmental or electrical constraints apply to the specific application environment.

Headers, Male Pins Selection Notes

Select this component when a single-row, 23-position connector is required for vertical or straight PCB mounting. Ensure the mating interface supports the 1.27 mm pitch standard. Consider the through-hole footprint dimensions during PCB layout to guarantee proper mechanical fit and electrical connectivity without interference from adjacent components.

Headers, Male Pins Part Context

This part belongs to Fischer Elektronik's line of male pin headers. It is specifically engineered for reliable signal transmission in compact electronic assemblies. The straight design facilitates direct vertical insertion into printed circuit boards, providing a stable connection point for cables or secondary boards within the system architecture.
