TAEABLSANF-25.000000

Oscillators Overview

The TAEABLSANF-25.000000 is a Voltage-Controlled Temperature-Compensated Crystal Oscillator (VCTCXO) manufactured by Taitien. It operates at a nominal frequency of 25 MHz and outputs a clipped sine wave signal. The device functions within a supply voltage range of 3V to 3.3V. It utilizes a 4-SMD, No Lead package with an exposed pad, measuring 7.00mm in length and 5.00mm in width. This component provides stable frequency generation suitable for applications requiring precise timing control.

Oscillators Feature Summary

• Voltage-controlled temperature compensation for enhanced frequency stability across varying thermal conditions
• Clipped sine wave output signal format optimized for specific interface requirements
• Exposed pad surface mount design facilitating efficient thermal dissipation from the device

Oscillators Applications

• Wireless communication modules requiring stable carrier frequencies
• GPS receiver systems needing precise timing references
• Portable electronic devices utilizing low-voltage power supplies

Oscillators Procurement Notes

Verify the specific output waveform requirement against system interface specifications, as this model provides a clipped sine wave rather than a standard square or CMOS signal. Confirm that the host circuitry can properly process this waveform type without additional conditioning components. Ensure the PCB layout accommodates the 7.00mm x 5.00mm footprint and the exposed pad thermal connection requirements for reliable operation.

Oscillators Selection Notes

Select this oscillator when temperature-compensated stability is required alongside voltage control capabilities for fine-tuning. The 3V to 3.3V operating range suits battery-powered or low-voltage digital systems. Consider the physical dimensions and exposed pad mounting style during mechanical design integration to ensure adequate thermal management and solder joint reliability.

Oscillators Part Context

This component belongs to Taitien's TA series of oscillators, specifically designed for applications demanding high frequency stability under environmental variations. The VCTCXO architecture combines crystal resonance with active compensation circuits to maintain accuracy. The 25 MHz frequency point is commonly used in clock distribution and reference signal generation within modern electronic assemblies.

Oscillators Replacement Considerations

XYCCCCNANF-25.000000
