TSM-104-03-L-SV-A-P

Headers, Male Pins Overview

The TSM-104-03-L-SV-A-P is a board connector manufactured by Samtec Inc. It features 3 contacts arranged in a single row of male pins. The connector utilizes straight surface mount terminals for PCB attachment. The mating contact finish consists of gold over nickel, while the tail termination uses matte tin with a nickel barrier. The housing material is black liquid crystal polymer (LCP) rated UL 94 V-0. The component includes an alignment pin feature and pegs for board mounting stability.

Headers, Male Pins Feature Summary

• Surface mount design with straight orientation for direct PCB integration
• Gold-plated mating contacts ensure reliable signal transmission
• Matte tin tails facilitate soldering during assembly
• Includes alignment pins and mounting pegs for precise positioning

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable to board connections
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact plating thickness, tail length, and mechanical features. Ensure the selected variant matches the required contact count and mounting style for the target application. Cross-reference RoHS compliance status with current regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a low-profile, surface-mount header with three positions is required. Consider the 0.100-inch pitch and unshrouded design for compatibility with mating cables or boards. Evaluate the need for alignment pins and pegs if precise placement and stability are critical for the manufacturing process.

Headers, Male Pins Part Context

This component belongs to the TSM series of flexible stacking solutions from Samtec. These connectors are designed for high-reliability applications requiring robust electrical connections in compact spaces. The series offers various configurations to suit different board spacing and density requirements.

Headers, Male Pins Replacement Considerations

Consult Samtec's official cross-reference tools for verified substitutes. Generic equivalents may not match the specific mechanical tolerances, plating specifications, or flexibility characteristics of the original part.
