TYS6045330M-10

$0.33

Description：FIXED IND 33UH 1.45A 137MOHM SMD
Series：TYS6045
Mfr：Laird-Signal Integrity Products
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e4f187b93e69 Category: Fixed Inductors Brand: Laird-Signal Integrity Products

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TYS6045330M-10 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Laird-Signal Integrity Products. Its product description is FIXED IND 33UH 1.45A 137MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for TYS6045330M-10

Description：FIXED IND 33UH 1.45A 137MOHM SMD
Series：TYS6045
Mfr：Laird-Signal Integrity Products
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：-
Inductance：33 µH
Tolerance：±20%
Current Rating (Amps)：1.45 A
Current - Saturation (Isat)：1.65A
Shielding：Shielded
DC Resistance (DCR)：137mOhm
Q @ Freq：-
Frequency - Self Resonant：7.8MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.236" L x 0.236" W (6.00mm x 6.00mm)
Height - Seated (Max)：0.185" (4.70mm)
Features：-

Fixed Inductors datasheet and documents for TYS6045330M-10

TYS6045330M-10

Fixed Inductors Overview

The TYS6045330M-10 is a shielded surface-mount power inductor from the Laird TYS series. It features a ferrite core and wirewound construction with an inductance of 33 µH and a tolerance of ±20%. The component supports a maximum DC current of 1.45 A and has a maximum DC resistance of 137 mOhms. Saturation current is rated at 1.8 A, with a self-resonant frequency of 11 MHz. Operating temperature ranges from -40°C to +125°C. Dimensions are 6.00 mm x 6.00 mm x 3.30 mm.

Fixed Inductors Feature Summary

Shielded wirewound design utilizing a ferrite core for magnetic containment
AEC-Q200 qualified for automotive reliability standards
Low profile surface mount package optimized for PCB space constraints

Fixed Inductors Applications

Automotive power conversion circuits
DC-DC converter output filtering
Noise suppression in signal integrity applications

Fixed Inductors Procurement Notes

Verify the manufacturer designation as Laird-Signal Integrity Products or Qnity depending on the specific supply chain source. Confirm RoHS3 compliance and AEC-Q200 qualification status through official datasheets before integration. Ensure the ordering suffix matches the required packaging format such as cut tape or reel.

Fixed Inductors Selection Notes

Select this component when high saturation current and low DCR are required within a standard 6x6 mm footprint. The 33 µH value suits intermediate frequency switching applications. Verify thermal performance under continuous load conditions given the 1.45 A rating. Compare against alternative TYS series variants if different height or inductance values are needed.

Fixed Inductors Part Context

This part belongs to the TYS Low Profile SMD Power Inductors family. The series offers various inductance values and current ratings within standardized footprints. The TYS6045 designation indicates the specific dimensional code for the 6x6 mm body size with associated height parameters.
