XZDGK53W-1

$0.41

Description：LED GREEN CLEAR CHIP SMD
Series：-
Mfr：SunLED
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:8cd45cfae7e4 Category: LED Indication - Discrete Brand: SunLED

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

XZDGK53W-1 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists SunLED. Its product description is LED GREEN CLEAR CHIP SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for XZDGK53W-1

Description：LED GREEN CLEAR CHIP SMD
Series：-
Mfr：SunLED
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：347mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.10mm x 0.80mm
Voltage - Forward (Vf) (Typ)：3.3V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount
Wavelength - Dominant：525nm
Wavelength - Peak：515nm
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：Chip LED
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.75mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for XZDGK53W-1

XZDGK53W-1

LED Indication - Discrete Overview

The XZDGK53W-1 is a green InGaN surface-mount LED from SunLED, housed in a 0603 (1608 metric) package. It emits at a peak wavelength of 515nm with a dominant wavelength of 525nm. The component features a water-clear lens and a typical forward voltage of 3.3V at a test current of 20mA. It offers a viewing angle of 130 degrees and meets RoHS3 standards.

LED Indication - Discrete Feature Summary

Utilizes InGaN technology for green light emission
Features a water-clear lens design
Supports standard surface-mount installation

LED Indication - Discrete Applications

General indicator lighting
Discrete LED applications
Electronic status indication

LED Indication - Discrete Procurement Notes

Verify the specific suffix to confirm packaging configuration, as variants such as XZDGK53W-6 exist with different handling formats. Ensure compatibility with MSL Level 3 moisture sensitivity requirements during storage and reflow processes. Confirm that the 0603 footprint aligns with the target PCB design constraints.

LED Indication - Discrete Selection Notes

Select this component for compact green indicator needs requiring a 0603 form factor. Consider the 3.3V forward voltage drop when designing drive circuits. Compare against similar models like XZMG53W-1 if lower voltage or different luminous intensity characteristics are required for the specific application environment.

LED Indication - Discrete Part Context

This part belongs to the XZDGK53 series of NanoPoint LEDs. It represents a standard discrete green LED solution suitable for space-constrained electronics. The product line emphasizes low-profile designs while maintaining reliable optical performance for visual signaling tasks.
